| Chipset | AMD 785G/SB710 |
| Form factor | ATX |
| CPU socket | Socket AM3 |
| Memory type | DDR III |
| DDR3-800 | Yes |
| DDR3-1066 | Yes |
| DDR3-1333 | Yes |
| DDR3-1600 | Yes |
| DDR3-1866 | No |
| DDR3-2133 | No |
| Memory slots | 4 |
| ECC | Yes |
| Max. RAM | 16384 MB |
| P-ATA | Yes |
| PCI 64-bit slots | 3 |
| PCI-E x1 | 1 |
| PCI-E x16 | 2 |
| CrossFire/SLI | CrossFire |
| AGP type | No AGP slots |
| Integrated sound adapter | Yes |
| Surround audio | 7.1 support |
| Toslink | Yes |
| Integrated graphics | Yes |
| Dedicated graphics memory | 128 MB |
| VGA outputs | 1 |
| HDMI outputs | 1 |
| DVI output | Yes |
| Number of LAN adapters | 1 integrated Ethernet adapter |
| LAN type | 1000Mbps |
| Integrated WLAN | No WLAN |
| USB ports | 6 |
| Firewire ports | 1 |
| PS/2 ports | 1 |
| eSATA ports | 1 |
| RS-232 | Yes |
| Manufacturer product code(s) | 90-MIBAC0-G0EAY0KZ / 90-MIBAC5-G0EAY0KZ / M4A785TD-V EVO / M4A785TD-V-EVO |
| UPC / EAN code(s) | 4719543172407 / 4719543174791 |
