| Chipset | AMD 770/SB710 |
| Form factor | ATX |
| CPU socket | Socket AM3 |
| Max number of CPUs | 1 |
| BIOS | AMI |
| Memory type | DDR III |
| DDR3-800 | No |
| DDR3-1066 | Yes |
| DDR3-1333 | Yes |
| DDR3-1600 | Yes |
| DDR3-1866 | No |
| DDR3-2133 | No |
| Memory slots | 4 |
| ECC | Yes |
| Max. RAM | 16384 MB |
| P-ATA | Yes |
| SATA | Yes |
| SATA RAID | Yes |
| SATA III / SATA-600 | No |
| SCSI | No |
| PCI slots | 3 |
| PCI-E x1 | 2 |
| PCI-E x16 | 1 |
| CrossFire/SLI | None |
| AGP type | No AGP slots |
| Integrated sound adapter | Yes |
| Surround audio | 7.1 support |
| Toslink | Yes |
| Integrated graphics | No |
| Number of LAN adapters | 1 integrated Ethernet adapter |
| LAN type | 1000Mbps |
| Integrated WLAN | No WLAN |
| USB ports | 6 |
| Firewire ports | 0 |
| PS/2 ports | 1 |
| RS-232 | No |
| Manufacturer product code(s) | 90-MIB9S0-G0EAY00Z / 90-MIB9S5-G0EAY00Z / 90-MIBB20-G0EAY0GZ / 90-MIBBL0-G0EAY0GZ / 90-MIBCA0-G0EAY0GZ / M4A77T / M4A77TD / M4A77TD PRO / M4A77TD PRO/U3S6 |
| UPC / EAN code(s) | 4719543171356 / 4719543173091 / 4719543174760 / 4719543174807 / 4719543176498 |
