| Chipset | NVIDIA GeForce 8200 |
| Form factor | Micro ATX |
| CPU socket | Socket AM2 |
| Memory type | DDR II |
| Supported memory speeds | DDR2-400 |
| Supported memory speeds | DDR2-533 |
| Supported memory speeds | DDR2-667/DDR2-800/DDR2-1066 |
| Memory slots | 2 |
| ECC | Yes |
| Max. RAM | 8192 MB |
| P-ATA | Yes |
| SATA | Yes |
| SATA RAID | Yes |
| PCI slots | 2 |
| PCI-E x1 | 1 |
| PCI-E x16 | 1 |
| Integrated sound adapter | Yes |
| Surround audio | 5.1 support |
| Integrated graphics | No |
| Number of LAN adapters | 1 integrated Ethernet adapter |
| LAN type | 1000Mbps |
| USB ports | 4 |
| PS/2 ports | 2 |
| Manufacturer product code(s) | 90-MIB7N0-G0EAY0GZ / M4N78-AM / M4N78-AM V2 |
| UPC / EAN code(s) | 4719543168578 / 4719543171363 |
