| Form factor | Micro ATX |
| CPU socket | Socket AM2 |
| Max number of CPUs | 1 |
| Max bus speed | 1000 MHz |
| BIOS | AMI |
| Memory type | DDR II |
| Supported memory speeds | DDR2-400?/DDR2-533/DDR2-667/DDR2-800 |
| Memory slots | 4 |
| ECC | No |
| Max. RAM | 8192 MB |
| SATA | Yes |
| SATA RAID | Yes |
| PCI slots | 2 |
| PCI-E x1 | 1 |
| PCI-E x16 | 1 |
| CrossFire/SLI | None |
| AGP type | No AGP slots |
| Integrated sound adapter | Yes |
| Surround audio | 7.1 support |
| Integrated graphics | Yes |
| Dedicated graphics memory | 128 MB |
| VGA outputs | 1 |
| HDMI outputs | 0 |
| DVI output | Yes |
| Number of LAN adapters | 1 integrated Ethernet adapter |
| LAN type | 100Mbps |
| Integrated WLAN | No WLAN |
| USB ports | 4 |
| Firewire ports | 0 |
| PS/2 ports | 1 |
| eSATA ports | 0 |
| RS-232 | Yes |
| UPC / EAN code(s) | 4711140874456 |
