| Chipset | Ati RD580 ja Ati SB600 |
| Form factor | ATX |
| CPU socket | Socket AM2 |
| Max number of CPUs | 1 |
| Max bus speed | 1000 MHz |
| BIOS | Award |
| Memory type | DDR II |
| Supported memory speeds | DDR2-400/DDR2-533/DDR2-667/DDR2-800 |
| Memory slots | 4 |
| ECC | No |
| Max. RAM | 32000 MB |
| P-ATA | Yes |
| SATA | Yes |
| SATA RAID | Yes |
| SCSI | No |
| PCI slots | 2 |
| PCI-E x1 | 1 |
| PCI-E x16 | 2 |
| CrossFire/SLI | CrossFire |
| AGP type | No AGP slots |
| Integrated sound adapter | Yes |
| Surround audio | 7.1 support |
| Toslink | Yes |
| Integrated graphics | No |
| Number of LAN adapters | 2 integrated Ethernet adapters |
| Integrated WLAN | No WLAN |
| USB ports | 4 |
| Firewire ports | 0 |
| PS/2 ports | 2 |
| eSATA ports | 0 |
| RS-232 | Yes |
